PORA
PRC-C4 Type
The PRC-C5 Type is a high-performance one-shaft powder clutch engineered to deliver stable and precise tension control in industrial applications. With its compact and durable design, this product ensures smooth torque transmission, quick response, and minimal wear, making it ideal for winding and unwinding processes in paper, film, yarn, and wire production. Easy to install and maintain, the PRC-C5 Type integrates seamlessly with manual, semi-automatic, or automatic tension controllers, providing manufacturers with a reliable solution to improve efficiency, product quality, and overall operational stability.
Product Specification
| Specification | PRC-2.5? | PRC-5C? | PRC-10C? | PRC-20C? | PRC-40C? |
|---|---|---|---|---|---|
| Torque (Nm) | 25 | 50 | 100 | 200 | 400 |
| Voltage (Vdc) | 24 | 24 | 24 | 24 | 24 |
| Resistor | 12.1 | 9.3 | 8.4 | 7.3 | 5.8 |
| Current (A) | 1.98 | 2.58 | 2.86 | 3.29 | 4.14 |
| Power (W) | 47.6 | 61.9 | 68.6 | 78.9 | 88.3 |
| Weight (Kg) | 10.1 | 18.2 | 35.7 | 53.3 | 104 |
| Time Constant (Sec) | 0.1 | 0.15 | 0.2 | 0.3 | 0.4 |
